Fully automatic float valve for the water level control made of stainless steel 304

feature

Small body, large displacement

This product is small and does not take up space, and it is superior to the traditional method to effectively increase water output, which is more than the traditional float valve.

No electricity/no workers fully automated working principle

When the water level in the water tower drops, the floating ball falls, and the pressure of the water in the water pipe is used to open the piston with the sealing silicone surface in the valve body, the valve body starts the water supply; when the water level in the water tower rises, the floating ball floats up, and the connecting rod drives the piston, and the silicone rubber body seals the water inlet, and the valve body stops the water supply. This product is used for automatic water level control of water tanks, water towers, swimming pools, water storage tanks, solar tanks, drinking water for livestock farming, etc. Automatic control of the water level can be achieved by connecting clean water with a pressure of more than 0 kg without electricity.

Safe and durable materials

The fully automatic 304 stainless steel water level control float valve is made of food-grade 304 stainless steel, ensuring the safety of drinking water. Featuring an exquisite appearance and durable hard shell, it has strong friction and shock resistance, effectively extending the service life of the product and making friction a problem in everyday life.

Wide range of applications

Compared with other ball valves, the stainless steel shell has a higher melting point, high temperature resistance, corrosion resistance, waterproof, and fire protection, making it widely used. This product is suitable for water tanks, water towers, pools, water basins, solar water tanks, and water storage tanks. No electricity is required, and clean water with a pressure of more than 0.2 kg is used to control the water level.

specification

Product material: Food-grade stainless steel

Screw material: stainless steel

Applicable temperature: 0-100 ° C

Working pressure range: ≤ 1.0MPa

Household tap water pressure: 0.3~0.5MPa

Pressure range: 0.2~10KG

Applicable media temperature: ≤ 1~80C

High temperature resistant media temperature: -20 ° C~100 ℃
